Wahoo 20 Trail is a light and tough kids’ bike that’s ready to roll off-road. Its sturdy aluminium frame is easy to manoeuvre as they weave their way down the trail. Perfect for riders between 114 and 132 cm tall.
| Frame | Alpha Silver Aluminium, 20" |
|---|---|
| Fork | Wahoo 20" carbon, post-mount disc brake, ThruSkew 5 mm QR |
| Hub front | Formula DC-20, alloy, 6-bolt, 100 mm ThruSkew |
|---|---|
| Skewer front | 135x5 mm bolt-on |
| Hub rear | Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm QR |
| Skewer rear | 169x5 mm bolt-on |
| Rim | Alloy 20", 28 h |
| Spokes | 14 g stainless steel, black |
| Tyre | Kenda Amrak, 30 tpi, 20x2.20" |
| Max tyre size | 2.40" with or without mudguards |
| Shifter | microSHIFT Advent Quick Trigger Pro SL-M6295, 9-speed |
|---|---|
| Rear derailleur | microSHIFT Advent RD-M6195S, 34-38T max cog |
| Crank | ProWheel alloy, 30T narrow-wide ring, 115 mm length |
| Bottom bracket | Sealed cartridge, 68 mm |
| Cassette | microSHIFT Advent H093, 11-38, 9-speed |
| Chain | KMC X9 |
| Pedal | VP-225 nylon platform |
| Saddle | Kids' padded, integrated seat post, Blendr light mount, 31.6x230 mm |
|---|---|
| Handlebar | Bontrager alloy, 31.8 mm clamp, 20 mm rise, 580 mm width |
| Grips | Kids' grip, 110 mm width |
| Stem | Bontrager alloy, 31.8 mm clamp, 6-degree, 45 mm length |
| Head set | Integrated, sealed cartridge bearings |
| Brake | Tektro HD-J285 hydraulic disc, short reach |
| Brake rotor | Tektro, 6-bolt, 160mm |
| Rotor size | Max brake rotor sizes: 160 mm front and rear |
| Mudguard | Trek custom |
|---|
| Weight | 9.80 kg / 21.61 lbs |
|---|---|
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider,and cargo) of 36 kg (80 lb). |
